Location:Home > Product > HSB series > HSB-006(1-6)
Product description
Product Details
| Ferrule | |
| Connector pin count | 6+PE |
| - rated current | 35A |
| - Relatively rated voltage | 400V |
| - phase-to-phase rated voltage | 690V |
| -rated pulse voltage | 6KV |
| - pollution level | 3 |
| -or | 35A 500V 6KV 3 |
| According to UL / CSA rated voltage | 600V |
| Insulation resistance | ≥1010Ω |
| material | Polycarbonate |
| range of working temperature | -40℃...+125℃ |
| Flammability rating | V0 |
| Number of pluggable | ≥500 |
| Pin | |
| material | Copper alloy |
| Surface treatment | silver |
| Contact resistance | ≤1mΩ |
| Screw connection | |
| - wire size | 1.5-6mm2 |
| －AWG | 10 |
| -Tightening torque | 1.2Nm |
