Product description
Product Details
| Ferrule | |
| Connector pin count | 5+PE |
| Electrical data according to DIN EN 61984 | |
| - rated current | 10A |
| - rated voltage | 400V |
| -rated pulse voltage | 6KV |
| - pollution level | 3 |
| According to the rated voltage of UL/CSA | 600V |
| Insulation resistance | ≥1010Ω |
| material | Polycarbonate |
| range of working temperature | -40℃...+125℃ |
| Flame retardant rating (UL94) | V0 |
| Number of pluggable | ≥500 |
| Pin | |
| material | Copper alloy |
| Surface treatment | Silver plated |
| Contact resistance | ≤3mΩ |
| Cold pressure connection | |
| ---mm2 | 0.14-2.5mm2 |
| ---AWG | 26-14 |
| PE screw connection | |
| ---mm2 | 2.5mm2 |
| ---AWG | 14 |
