Product description
Product Details
| Ferrule | |
| Connector pin count | 16+PE |
| Rated current | 16A |
| Rated voltage | 500V |
| Degree of pollution | 3 |
| Rated pulse voltage | 6KV |
| Insulation resistance | ≥1010Ω |
| material | Polycarbonate |
| range of working temperature | -40℃...+125℃ |
| Flame retardant rating (UL94) | V0 |
| According to UL / CSA rated voltage | 600V |
| Number of pluggable | ≥500 |
| Pin | |
| material | Copper alloy |
| Surface treatment | silver |
| Gold plating | |
| Contact resistance | ≤1mΩ |
| Wiring form | Screw connection |
| Wire specification | 0.75-2.5mm2 AWG 18-14 |
| Tightening torque | 0.5N·m |
Stripping length | 7.0mm |
