| Ferrule | |
| Connector pin count | 40+PE |
| - rated current | 10A |
| - rated voltage | 250V |
| -rated pulse voltage | 4KV |
| - pollution level | 3 |
| - parameters when pollution level 2 | 10A 230/400V 4KV 2 |
| -Based on UL/CSA rated voltage | 600V |
| - rated voltage according to CSA winding connection | 2A 30V |
| Insulation resistance | ≥1010Ω |
| material | Polycarbonate |
| range of working temperature | -40℃...+125℃ |
| Flammability rating | V0 |
| Number of pluggable | ≥500 |
| Pin | |
| material | Copper alloy |
| Surface treatment | Silver plated |
| Contact resistance | ≤3mΩ |
| Cold pressure connection | |
| - wire size | 0.14-2.5mm2 |
| －AWG | 26-14 |
